Saginomiya SNS Stainless Steel Single Pressure Control (Manual Reset)
View item in Hamer catalogue: Control on page 10
Features
  • Stainless steel, single pressure control with manual reset.
  • For use with ammonia, fluorinated refrigerants as well as with air and water.
  • Allowable fluid temp: -20°C - 120°C.
  • Supplied with mounting bracket.
  • SPDT contact mechanism.
  • 1/4" - 18 NPT female thread.



Electrical Ratings Power Factor (COSФ)

  • Non-inductive current: 1 | Inductive current - Full load: 0.75, Locked Rotor: 0.45

Electrical Ratings 125/250V AC

  • Non-inductive current: 12 | Inductive current - Full load: 12, Locked Rotor: 72
Code Cat# Pressure Range Notes
SG262 SNS-C106XM2N Range: -60 to 600KPa (-8.7 to 87 PSI) Manual reset. Trips on pressure decrease. Indent Item
SG291 SNS-C130XM2N Range: 500 to 3000KPa (72.5 to 435.1 PSI) Manual reset. Trips on pressure decrease Indent Item
(No drawing available)
