STARPAD II SE7071TC2 - 15W/100W

STARPAD SE707 50TC2

SAL

Features

5W/100W IP65 LED floodlight with selectable CCT

Application: A versatile floodlight solution for residential & commercial exterior spaces

Specifications

Robust die-cast aluminium body, IK07-rated
Durable black powder-coated finish
Textured, tempered glass front cover
High-efficiency LED optics, CRI >80, selectable CCT 3000K/4000K/5000K
Non-dimmable LED driver, high-performance aluminium reflector, beam distribution 110°
Nickel-plated copper cable gland with 600mm, 3-core rubber flex (15W-30W models), 800mm for (50W-100W models)

Code	Description	Power (W)	Lumen (lm)	CCT (K)	Beam Angle	CRI	Dim LxWxH (mm)
SE7071-15TC2BK	STARPAD II Floodlight with selectable CCT, 15W	15	1575/1800/1650	3000/4000/5000	110°	80	153 x 99 x 36
SE7071-30TC2BK	STARPAD II Floodlight with selectable CCT, 30W	30	3150/3600/3300	3000/4000/5000	110°	80	1207 x 135 x36
SE7071-50TC2BK	STARPAD II Floodlight with selectable CCT, 50W	50	5250/6000/5500	3000/4000/5000	110°	80	261 x 171 x 39
SE7071-100TC2-BK	STARPAD II Floodlight with selectable CCT, 100W	100	10500/12000/11000	3000/4000/5000	110°	80	343 x 200 x 42

(No drawing available)

SE7071-30TC2BK.pdf 694 KB
