SAL SOL Under Veranda EM-LED GR IP65
sl9726 20tc less perspective no gland 1
Features

Maintained emergency, IP65 LED weatherproof batten with selectable colour

Application
Commercial or industrial utility applications requiring IP65 and IK08 performance

Design Specifications

  • Colour temperature selectable by DIP switch, 3000 /4000 /6000K
  • Rounded shape vandal-proof design, robust polycarbonate body and UV stabilized polycarbonate diffuser
  • Stainless steel clips & screws, 20mm cable gland entry
  • Integral constant current non-dimmable LED driver
  • Compliant to AS/NZS2293 Emergency Lighting & Exit Signs, guaranteed minimum 90 minutes emergency mode function with LiFePO4 battery technology. Emergency classification (20w) D32@C0, D20@C90, (40w) D40@C0, D20@C90
  • Accessories included - PVC cable glands and suspension brackets. Installation types - Surface mount (standard) or if Suspended (a suspension kit is required).
SAL Logo 01
Code Cat# Description Input Voltage (V/AC) Power (W) Lumens (lm) CRI Dim (mm)
SL9726-20TC-EM SL9726/20TC/EM WEATHERPROOF 20W TC IP65 EM 240 20 1800 80 642(L) x 118(W) x 77(H)
SL9726-40TC-EM SL9726/40TC/EM WEATHERPROOF 40W TC IP65 EM 240 42 3600 80 1251(L) x 118(W) x 77(H)
SL9726-50TC-EM SL9726/50TC/EM WEATHERPROOF 1551mm IP65 30/50W TC EM 240 50 5480/6070/6070 80 1551(L) x 118(W) x 77(H)
(No drawing available)
