SAL PREMIER Downlight IP64 30/40W LED
s9074xtc3
Features

Non-dimmable IP64, 40W LED downlight with selectable colour temperature and power

Application
Ideal for any commercial interior space

Design Specifications

  • Premium aluminium body profile, CA90 rated
  • Stylish white powder coat finish
  • Quality opal polycarbonate diffuser
  • High-efficiency SMD LED chips
  • Constant current remote non-dimmable LED driver, with flex and plug

Performance
Dimmable - OPTIONAL
Dimmer Type - Dual power, 1-10V, DALI / DSI - Half power, trailing edge, 1-10V, DALI / DSI

SAL Logo 01
Code Cat# Description Input Voltage (V/AC) Multiple Wattage Lumens (lm) CCT (K) Beam Angle CRI Dim (mm) Cutout Size (mm)
S9076TC-WH-DP S9076TC/WH/DP LED D/L 30/40W IP64 3/4/6K WH DP 240 30/40 3500/4200/3800 3000/4000/5700 90 deg 80 280(W) x 96(H) 240
S9076TC WH DP + HP photometric image
